WB (Western Blot)
(Western blot analysis of extracts from 293 cells, using KCNA5 antibody.The lane on the left is treated with the antigen-specific peptide.)
Rabbit KCNA5 Polyclonal Antibody | anti-KCNA5 antibody
KCNA5 Antibody
Gene Names
KCNA5; HK2; HCK1; PCN1; ATFB7; HPCN1; KV1.5
Reactivity
Human, Mouse, Rat
Applications
ELISA, Immunocytochemistry, Immunofluorescence, Western Blot
Purity
The antiserum was purified by peptide affinity chromatography using SulfoLink Coupling Resin.
Synonyms
KCNA5, Antibody; KCNA5 Antibody; ATFB7; cardiac potassium channel; HCK1; HK2; HPCN1; insulinoma and islet potassium channel; KCNA5; KCNA5_HUMAN; KV1.5; PCN1; potassium channel 1; Potassium channel, insulinoma and islet cell; Potassium channel, voltage-gated, shaker-related subfamily, member 5; Potassium voltage gated channel subfamily A member 5; Potassium voltage-gated channel subfamily A member 5; Voltage-gated potassium channel HK2; voltage-gated potassium channel protein Kv1.5; Voltage-gated potassium channel subunit Kv1.5; anti-KCNA5 antibody
Host
Rabbit
Reactivity
Human, Mouse, Rat
Clonality
Polyclonal
Isotype
IgG
Specificity
KCNA5 antibody detects endogenous levels of total KCNA5
Purity/Purification
The antiserum was purified by peptide affinity chromatography using SulfoLink Coupling Resin.
Form/Format
Liquid
Phosphate buffered saline, pH 7.4, 150mM NaCl, 0.02% sodium azide and 50% glycerol.
Phosphate buffered saline, pH 7.4, 150mM NaCl, 0.02% sodium azide and 50% glycerol.
Concentration
1mg/ml (varies by lot)
Sequence Length
613
Applicable Applications for anti-KCNA5 antibody
ELISA, ICC (Immunocytochemistry), IF (Immunofluorescence), WB (Western Blot)
Immunogen
A synthesized peptide
Subcellular Location
Membrane.
Tissue Specificity
Pancreatic islets and insulinoma.
Predicted Cross Reactivity
Pig, Bovine, Horse, Rabbit, Dog
Similarity
Pig (100%), Bovine (100%), Horse (100%), Rabbit (90%), Dog (100%)
Conjugation
Unconjugated
Preparation and Storage
Store at -20 degree C. Stable for 12 months from date of receipt.
WB (Western Blot)
(Western blot analysis of extracts from 293 cells, using KCNA5 antibody.The lane on the left is treated with the antigen-specific peptide.)
WB (Western Blot)
(Western blot analysis of extracts from 293 cells, using KCNA5 antibody.The lane on the left is treated with the antigen-specific peptide.)
IF (Immunofluorescence)
(AAA324970 staining 293 cells by IF/ICC. The sample were fixed with PFA and permeabilized in 0.1% Triton X-100, then blocked in 10% serum for 45 minutes at 25 degree C. The primary antibody was diluted at 1/200 and incubated with the sample for 1 hour at 37 degree C. An Alexa Fluor 594 conjugated goat anti-rabbit IgG (H+L) antibody, diluted at 1/600, was used as secondary antibody.)
IF (Immunofluorescence)
(AAA324970 staining 293 cells by IF/ICC. The sample were fixed with PFA and permeabilized in 0.1% Triton X-100, then blocked in 10% serum for 45 minutes at 25 degree C. The primary antibody was diluted at 1/200 and incubated with the sample for 1 hour at 37 degree C. An Alexa Fluor 594 conjugated goat anti-rabbit IgG (H+L) antibody, diluted at 1/600, was used as secondary antibody.)
Related Product Information for anti-KCNA5 antibody
Function: Voltage-gated potassium channel that mediates transmembrane potassium transport in excitable membranes. Forms tetrameric potassium-selective channels through which potassium ions pass in accordance with their electrochemical gradient. The channel alternates between opened and closed conformations in response to the voltage difference across the membrane. Can form functional homotetrameric channels and heterotetrameric channels that contain variable proportions of KCNA1, KCNA2, KCNA4, KCNA5, and possibly other family members as well; channel properties depend on the type of alpha subunits that are part of the channel (PubMed:12130714). Channel properties are modulated by cytoplasmic beta subunits that regulate the subcellular location of the alpha subunits and promote rapid inactivation (PubMed:12130714). Homotetrameric channels display rapid activation and slow inactivation (PubMed:8505626, PubMed:12130714). May play a role in regulating the secretion of insulin in normal pancreatic islets. Isoform 2 exhibits a voltage-dependent recovery from inactivation and an excessive cumulative inactivation (PubMed:11524461).
Subunit Structure: Homotetramer and heterotetramer of potassium channel proteins. Interacts with DLG1, which enhances channel currents. Forms a ternary complex with DLG1 and CAV3 (By similarity). Interacts with KCNAB1 (PubMed:12130714). Interacts with UBE2I (PubMed:17261810).
Post-translational Modifications: Sumoylated on Lys-221, and Lys-536, preferentially with SUMO3. Sumoylation regulates the voltage sensitivity of the channel.
Similarity: The amino terminus may be important in determining the rate of inactivation of the channel while the C-terminal PDZ-binding motif may play a role in modulation of channel activity and/or targeting of the channel to specific subcellular compartments.The transmembrane segment S4 functions as voltage-sensor and is characterized by a series of positively charged amino acids at every third position. Channel opening and closing is effected by a conformation change that affects the position and orientation of the voltage-sensor paddle formed by S3 and S4 within the membrane. A transmembrane electric field that is positive inside would push the positively charged S4 segment outwards, thereby opening the pore, while a field that is negative inside would pull the S4 segment inwards and close the pore. Changes in the position and orientation of S4 are then transmitted to the activation gate formed by the inner helix bundle via the S4-S5 linker region. Belongs to the potassium channel family. A (Shaker) (TC 1.A.1.2) subfamily. Kv1.5/KCNA5 sub-subfamily.
Subunit Structure: Homotetramer and heterotetramer of potassium channel proteins. Interacts with DLG1, which enhances channel currents. Forms a ternary complex with DLG1 and CAV3 (By similarity). Interacts with KCNAB1 (PubMed:12130714). Interacts with UBE2I (PubMed:17261810).
Post-translational Modifications: Sumoylated on Lys-221, and Lys-536, preferentially with SUMO3. Sumoylation regulates the voltage sensitivity of the channel.
Similarity: The amino terminus may be important in determining the rate of inactivation of the channel while the C-terminal PDZ-binding motif may play a role in modulation of channel activity and/or targeting of the channel to specific subcellular compartments.The transmembrane segment S4 functions as voltage-sensor and is characterized by a series of positively charged amino acids at every third position. Channel opening and closing is effected by a conformation change that affects the position and orientation of the voltage-sensor paddle formed by S3 and S4 within the membrane. A transmembrane electric field that is positive inside would push the positively charged S4 segment outwards, thereby opening the pore, while a field that is negative inside would pull the S4 segment inwards and close the pore. Changes in the position and orientation of S4 are then transmitted to the activation gate formed by the inner helix bundle via the S4-S5 linker region. Belongs to the potassium channel family. A (Shaker) (TC 1.A.1.2) subfamily. Kv1.5/KCNA5 sub-subfamily.
NCBI and Uniprot Product Information
NCBI GI #
NCBI GeneID
NCBI Accession #
NCBI GenBank Nucleotide #
Molecular Weight
Observed: 68 kD
Predicted: 68 kDa
Predicted: 68 kDa
NCBI Official Full Name
potassium voltage-gated channel subfamily A member 5
NCBI Official Synonym Full Names
potassium voltage-gated channel subfamily A member 5
NCBI Official Symbol
KCNA5
NCBI Official Synonym Symbols
HK2; HCK1; PCN1; ATFB7; HPCN1; KV1.5
NCBI Protein Information
potassium voltage-gated channel subfamily A member 5
UniProt Protein Name
Potassium voltage-gated channel subfamily A member 5
UniProt Gene Name
KCNA5
Similar Products
Product Notes
The KCNA5 kcna5 (Catalog #AAA324970) is an Antibody produced from Rabbit and is intended for research purposes only. The product is available for immediate purchase. The KCNA5 Antibody reacts with Human, Mouse, Rat and may cross-react with other species as described in the data sheet. AAA Biotech's KCNA5 can be used in a range of immunoassay formats including, but not limited to, ELISA, ICC (Immunocytochemistry), IF (Immunofluorescence), WB (Western Blot). Researchers should empirically determine the suitability of the KCNA5 kcna5 for an application not listed in the data sheet. Researchers commonly develop new applications and it is an integral, important part of the investigative research process. It is sometimes possible for the material contained within the vial of "KCNA5, Polyclonal Antibody" to become dispersed throughout the inside of the vial, particularly around the seal of said vial, during shipment and storage. We always suggest centrifuging these vials to consolidate all of the liquid away from the lid and to the bottom of the vial prior to opening. Please be advised that certain products may require dry ice for shipping and that, if this is the case, an additional dry ice fee may also be required.Precautions
