FCM/FACS (Flow Cytometry)
(Flow cytometry using the anti- 4-1BBL antibody AT113-2 . RAW264.7 cells were fixed using 2% PFA and stained with anti-unknown specificity antibody or the rabbit IgG1 version of AT113-2 at a dilution of 1:100 for 1h at RT. After washing, the bound antibody was detected using a goat anti-rabbit IgG AlexaFluor 488 antibody at a dilution of 1:1000 and cells analyzed using a FACSCanto flow-cytometer.)
Rat anti-Mouse 4-1BBL Monoclonal Antibody | anti-4-1BBL antibody
Anti-4-1BBL [AT113-2]
Gene Names
Tnfsf9; Ly63l; 4-1BBL; Cd137l; 4-1BB-L; AI848817
Reactivity
Mouse
Applications
Western Blot, Flow Cytometry, Functional Assay
Purity
Purified antibody. Protein A affinity purified
Synonyms
4-1BBL, Antibody; Anti-4-1BBL [AT113-2]; CD137L; TNFSF9; 4-1BB ligand; 41BBL; CDw137L; homolog of mouse 4-1BB-L; receptor 4-1BB ligand; tumor necrosis factor (ligand) superfamily member 9; tumor necrosis factor (ligand) superfamily, member 9; tumor necrosis factor ligand 5A; Tumor necrosis factor ligand superfamily member 9; anti-4-1BBL antibody
Host
Rat
Reactivity
Mouse
Clonality
Monoclonal
Isotype
Rat IgG1, kappa
Clone Number
AT113-2
Specificity
This antibody is specific for 4-1BB ligand (also known as CD137 ligand), which is a member of the TNF superfamily and is a type II membrane protein. 4-1BB ligand is a co-stimulatory molecule that is expressed on antigen presenting cells (DCs, monocytes/macrophages, B cells) and is upregulated upon activation of these cells. Both of the 4-1BB ligand and its receptor, TNFRSF9/4-1BB, are involved in the antigen presentation process and in the generation of cytotoxic T cells. In direct ELISAs, no cross?reactivity with recombinant human RELT is observed.
Purity/Purification
Purified antibody. Protein A affinity purified
Form/Format
PBS with 0.02% Proclin 300.
Concentration
1mg/ml (varies by lot)
Applicable Applications for anti-4-1BBL antibody
Blocking, WB (Western Blot), FCM/FACS (Flow Cytometry)
PMID
17311995
Preparation and Storage
Store at 4 degree C for up to 3 months. For longer storage, aliquot and store at -20 degree C.
FCM/FACS (Flow Cytometry)
(Flow cytometry using the anti- 4-1BBL antibody AT113-2 . RAW264.7 cells were fixed using 2% PFA and stained with anti-unknown specificity antibody or the rabbit IgG1 version of AT113-2 at a dilution of 1:100 for 1h at RT. After washing, the bound antibody was detected using a goat anti-rabbit IgG AlexaFluor 488 antibody at a dilution of 1:1000 and cells analyzed using a FACSCanto flow-cytometer.)
FCM/FACS (Flow Cytometry)
(Flow cytometry using the anti- 4-1BBL antibody AT113-2 . RAW264.7 cells were fixed using 2% PFA and stained with anti-unknown specificity antibody or the rabbit IgG1 version of AT113-2 at a dilution of 1:100 for 1h at RT. After washing, the bound antibody was detected using a goat anti-rabbit IgG AlexaFluor 488 antibody at a dilution of 1:1000 and cells analyzed using a FACSCanto flow-cytometer.)
IF (Immunofluorescence)
(Immunofluorescence staining of fixed RAW264.7 cells with anti-4-1BBL antibody AT113-2 Immunofluorescence analysis of paraformaldehyde fixed RAW264.7 cells on Shi-fix coverslips stained with the chimeric rabbit IgG version of AT113-2 at 10ug/ml for 1h followed by Alexa Fluor 488 secondary antibody (2ug/ml), showing membrane staining. The nuclear stain is DAPI (blue). Panels show from left-right, top-bottom DAPI, merged channels and an isotype control. The isotype control was an unknown specificity antibody followed by staining with Alexa Fluor 488 secondary antibody.)
IF (Immunofluorescence)
(Immunofluorescence staining of fixed RAW264.7 cells with anti-4-1BBL antibody AT113-2 Immunofluorescence analysis of paraformaldehyde fixed RAW264.7 cells on Shi-fix coverslips stained with the chimeric rabbit IgG version of AT113-2 at 10ug/ml for 1h followed by Alexa Fluor 488 secondary antibody (2ug/ml), showing membrane staining. The nuclear stain is DAPI (blue). Panels show from left-right, top-bottom DAPI, merged channels and an isotype control. The isotype control was an unknown specificity antibody followed by staining with Alexa Fluor 488 secondary antibody.)
Related Product Information for anti-4-1BBL antibody
Recombinant monoclonal antibody to 4-1BBL. Recombinant Platform with variable regions (i.e. specificity) from the hybridoma AT113-2.
This antibody was raised by immunising LOU rats with soluble recombinant 4-1BBL:Fc fusion protein.
This antibody was raised by immunising LOU rats with soluble recombinant 4-1BBL:Fc fusion protein.
Product Categories/Family for anti-4-1BBL antibody
References
French Ruth et al. Eradication of lymphoma by CD8 T cells following anti-CD40 monoclonal antibody therapy is critically dependent on CD27 costimulation. Blood. 2007 Jun 1;109(11):4810-5.
Note on publication: Describe the generation of this antibody and its subsequent use alongside with other antibodies to demonstrate that the eradication of lymphoma by CD8 T cells following anti-CD40 monoclonal antibody therapy is critically dependent on CD27 costimulation.
Note on publication: Describe the generation of this antibody and its subsequent use alongside with other antibodies to demonstrate that the eradication of lymphoma by CD8 T cells following anti-CD40 monoclonal antibody therapy is critically dependent on CD27 costimulation.
NCBI and Uniprot Product Information
NCBI GI #
NCBI GeneID
NCBI Accession #
NCBI GenBank Nucleotide #
UniProt Accession #
Molecular Weight
33,853 Da
NCBI Official Full Name
tumor necrosis factor ligand superfamily member 9
NCBI Official Synonym Full Names
tumor necrosis factor (ligand) superfamily, member 9
NCBI Official Symbol
Tnfsf9
NCBI Official Synonym Symbols
Ly63l; 4-1BBL; Cd137l; 4-1BB-L; AI848817
NCBI Protein Information
tumor necrosis factor ligand superfamily member 9; 4-1BB ligand
UniProt Protein Name
Tumor necrosis factor ligand superfamily member 9
UniProt Gene Name
Tnfsf9
UniProt Synonym Gene Names
Cd137l; Cd157l; Ly63l; 4-1BBL
UniProt Entry Name
TNFL9_MOUSE
Similar Products
Product Notes
The 4-1BBL tnfsf9 (Catalog #AAA72110) is an Antibody produced from Rat and is intended for research purposes only. The product is available for immediate purchase. The Anti-4-1BBL [AT113-2] reacts with Mouse and may cross-react with other species as described in the data sheet. AAA Biotech's 4-1BBL can be used in a range of immunoassay formats including, but not limited to, Blocking, WB (Western Blot), FCM/FACS (Flow Cytometry). Researchers should empirically determine the suitability of the 4-1BBL tnfsf9 for an application not listed in the data sheet. Researchers commonly develop new applications and it is an integral, important part of the investigative research process. It is sometimes possible for the material contained within the vial of "4-1BBL, Monoclonal Antibody" to become dispersed throughout the inside of the vial, particularly around the seal of said vial, during shipment and storage. We always suggest centrifuging these vials to consolidate all of the liquid away from the lid and to the bottom of the vial prior to opening. Please be advised that certain products may require dry ice for shipping and that, if this is the case, an additional dry ice fee may also be required.Precautions
